UltraFiltration (UF) + Reverse Osmosis (RO) Purification
This system combines UltraFiltration (UF) and Reverse Osmosis (RO) to deliver multiple layers of water purification. The UF membrane helps reduce sediment, suspended solids, and many microorganisms, while protecting the RO membrane from premature wear. Water then passes through the advanced RO membrane, which helps reduce dissolved contaminants, water hardness, heavy metals, fluoride, nitrates, and other impurities.
Why Use UF and RO Together?
UF serves as a pre-treatment stage that helps protect the RO membrane by reducing suspended solids before they reach the RO system. Benefits of combining UF and RO include:
Cleaner Water Than Traditional Filters
Many water filters focus primarily on chlorine and taste. UF + RO filtration targets a much broader range of contaminants for greater peace of mind.
Better Tasting Coffee, Tea & Ice
By reducing dissolved impurities, water tastes cleaner and allows beverages and food to reach their full flavor potential.
Helps Protect Your Family
Provides advanced filtration against contaminants that may not be visible, detectable by taste, or removable by basic filtration systems.
Longer System Life
The UF membrane helps protect the RO membrane from excess sediment and suspended solids, improving efficiency and extending filter life.
Reduced Reliance on Bottled Water
Enjoy purified water directly from your system while reducing the ongoing cost and inconvenience of bottled water.
The Result
When combined, UltraFiltration and Reverse Osmosis create a multi-layer purification process that addresses both visible and invisible contaminants. UF helps remove particles and microorganisms, while RO provides deeper purification by reducing dissolved contaminantsādelivering cleaner, fresher, and higher-quality drinking water.
Ā
|
TURBO UF |
TURBO UF/RO |
SHARP UF |
SHARP UF/RO |
Hybrid UF |
Hybrid UF/RO |
| No Plastic Jugs |
 |
|
|
|
|
|
| Cold Water |
|
|
|
|
|
|
| Hot WaterĀ |
|
|
|
|
|
|
| Child Safety for Hot Water |
 |
|
|
|
|
|
| UltraFiltration (UF) |
|
|
|
|
|
|
| Reverse Osmosis (RO) |
|
|
|
|
|
|
| Waste Water |
|
|
|
|
|
|
| Stainless Steel Holding Tank |
|
|
|
|
|
|
| Polypropylene Holding Tank |
|
|
|
|
|
|
Ā
Ā Features
- Built-in filtration system
- Easy to use
- Separate hot/cold power switch
- Automatic hot and cold water temperature control
- Automatic heating shut-off when hot temperature is reached
- Automatic float valve
- High efficiency sealed compressor cooling system
- Type 304 stainless steel hot and cold water tanks
- Easy access front panel for service of filter system
- Easy to clean
|
Specifications
- Weight: 45 lbs.
- Premium Turbo weight: 56 lbs.
- Turbo dimensions: (D) 13ā x (W) 13ā x (H) 37.5ā
- Premium Turbo dimensions: (D) 13ā x (W) 13ā x (H) 50āĀ
- Heating power: 500W 6.2 Amps
-
Cooling power: 112W 2.4 Amps -Ā TOTAL NEEDED 612W 8.6 Amps
- Hot water tank volume: 0.5 gal/heating
- Cold water tank volume: .54 gal
- Cooling capacity: 1.95 gal per hour 35-50Ā°F
- Heating capacity: 1.5 gal per hour 185Ā°F
- Voltage: 110V-120V 50/60Hz
- Pressure range: 30-60 psi (2.1-4.1bar)
- Optimum service flow: 0.50 GPM at 60 psi (1.1 lpm at 4.1 bar)
|
Specifications
ā¢ Floor weight: 45lbs. / 20kg
ā¢ Premium floor weight: 56lbs. / 25kgĀ
ā¢ Floor dimensions: 13āD x 13āW x 37.5āH / 33cm D x 33cm W x 95.25cm HĀ
ā¢ Premium floor dimensions: 13āD x 13āW x 50āH / 33cm D x 33cm W x 127cm HĀ
ā¢ Heating power: 500W, 6.2 ampsĀ
ā¢ Cooling power: 112W, 2.4 ampsĀ
ā¢ Hot water dispensing temperature: 176-194Ā°F / 80-90Ā°CĀ
ā¢ Cold water dispensing temperature: 35-50Ā°F / 1.7-10Ā°CĀ
ā¢ Hot water tank volume: 0.5 gallon / 1.9 litersĀ
ā¢ Cold water tank volume: .54 gallon / 2.04 litersĀ
ā¢ Heating capacity: 1.4 gallons per hour / 5.3 lphĀ
ā¢ Cooling capacity: 1.95 gallons per hour / 7.4 lphĀ
ā¢ Voltage: 110-120V / 220-230V-50/60 Hz
Replacement Cartridges
| Product Name |
SKU |
| GAC Cartridge (Inline) |
CQE-RC-04038
|
| UF Cartridge (Inline) |
CQE-RC-04039
|
| SMART Cartridge (Inline) |
CQE-RC-04040
|
| 50 GPD RO Membrane |
CQE-RC-04041
|
Product Manual
Water Cooler Manual
Product Brochure
WaterCoolors-TURBO+RO
